OUTDOOR LED Billboard
9m² , SMD LED Screen, 6500nits brightness, for DOOH.
LED Billboard
The outdoor LED digital billboard boasts an elegant design, equipped with a P5.91 SMD LED display, with brightness up to 6500nits, the visual size of the display screen is 3500mm x 2500mm, and the pole stand is 2500mm height.
Robust and elegant
IP65 LED screen covered by aluminum profile structure. the stand and the inside of the screen with robust galvanize structure steel. Its a perfect eye catching LED digital screen structure for Digital out of home.
Outstanding Screen
Star vision SMD LED screen equipped with SMD1921 LED bulbs, provide up to 6500 nits brightness, and with 3840HZ high refresh rate. the SMD mupi LED offers excellent contrast, optimal light distributions and great viewing angles.
We offer outstanding resolutions from P5.9 for 9 sqm display.
Smart Cooling
To enlarge the stability and lifetime of the LED screen, we built smart fan cooling system inside the Billboard to keep the temperature in a suitable range, which can avoid the overheat inside the machine.
Smart control CMS
The smart control system based on android 11, allows the client to control content via PC and mobile. With the smart control CMS, clients can also monitor the screens performance and condition remotely, including temperature, power, and other display parameters. The auto-brightness control together with a luminosity sensor will automatically adjust the brightness according to the environment.
Outdoor LED billboard
— 9m² , SMD LED Screen, 6500nits brightness, for DOOH.
The outdoor LED digital billboard boasts an elegant design, equipped with a P5.91 SMD LED display, with brightness up to 6500nits, the visual size of the display screen is 3500mm x 2500mm, and the pole stand is 2500mm height.
Robust and elegant
IP65 LED screen covered by aluminum profile structure. the stand and the inside of the screen with robust galvanize structure steel. Its a perfect eye catching LED digital screen structure for Digital out of home.
Outstanding Screen
Star vision SMD LED screen equipped with SMD1921 LED bulbs, provide up to 6500 nits brightness, and with 3840HZ high refresh rate. the SMD mupi LED offers excellent contrast, optimal light distributions and great viewing angles.
We offer outstanding resolutions from P5.9 for 9 sqm display.
Smart Cooling
To enlarge the stability and lifetime of the LED screen, we built smart fan cooling system inside the Billboard to keep the temperature in a suitable range, which can avoid the overheat inside the machine.
Smart control CMS
The smart control system based on android 11, allows the client to control content via PC and mobile. With the smart control CMS, clients can also monitor the screens performance and condition remotely, including temperature, power, and other display parameters. The auto-brightness control together with a luminosity sensor will automatically adjust the brightness according to the environment.
Product Specs
| Pixel Pitch(mm) | 5.95 |
| Pixel Configuration | 1R1G1B |
| Real Pixel Resolutions (Pixels/m²) | 65217 |
| LED encapsulation | SMD1921 |
| Module size L*H(mm) | 500*250 |
| Module resolution(pixels) | 84*42 |
| Brand of LEDs | Nationstar |
| Brand of power | Meanwell |
| Cabinet type | Waterproof cabinet |
| Cabinet material | Aluminum |
| Physical cabinet resolution(pixels) | 1000*1000 |
| Waterproof level | IP65 |
| Max. power consumption(w/m²) | 850 |
| Average power consumption(w/m²) | 350 |
| Operation platform | Windows |
| Control mode | Synchronized control |
| Other specifications | |
| Brightness(nits)/m² | ＞6500 |
| Refreshing frequency | ＞1920 |
| Best viewing distance (m) | 5.91 |
| Best view angle | 160°/160° |
| Drive method | 1/6 scan |
| Operation temperature | -20°C+60°C |
| Operating voltage | 220/110V/AC 50Hz +-10% |
| Brightness adjustment | Software/Manual |
| Pixel Pitch(mm) | 5.95 |
| Pixel Configuration | 1R1G1B |
| Real Pixel Resolutions (Pixels/m²) | 65217 |
| LED encapsulation | SMD1921 |
| Module size L*H(mm) | 500*250 |
| Module resolution(pixels) | 84*42 |
| Brand of LEDs | Nationstar |
| Brand of power | Meanwell |
| Cabinet type | Waterproof cabinet |
| Cabinet material | Aluminum |
| Physical cabinet resolution(pixels) | 1000*1000 |
| Waterproof level | IP65 |
| Max. power consumption(w/m²) | 850 |
| Average power consumption(w/m²) | 350 |
| Operation platform | Windows |
| Control mode | Synchronized control |
| Other specifications | |
| Brightness(nits)/m² | ＞6500 |
| Refreshing frequency | ＞1920 |
| Best viewing distance (m) | 5.91 |
| Best view angle | 160°/160° |
| Drive method | 1/6 scan |
| Operation temperature | -20°C+60°C |
| Operating voltage | 220/110V/AC 50Hz +-10% |
| Brightness adjustment | Software/Manual |
